FieldServer B35XX Multiport Gateway

The FS-B35XX is designed to meet the needs of any system integrator in designing a complete interoperable system. The FS-B30XX Series brings together the powerful FieldServer driver library with state-of-the-art gateway design.

The FS-B35XX comes in 6 different variations:

  • B3510:This is your run of the mill B35XX, comes with four serial connections (two RS-232, two RS-485), two 10/100 Ethernet ports, and a LonWorks (Free Topology - FT) port. Perfect for most standard integrations.
  • B3512: This gateway is specialized for Profibus DP Slave Protocol integrations.
  • B3514:This gateway is specialized for ControlNet Slave Protocol integrations.
  • B3515:This gateway is specialized for DeviceNet Slave Protocol integrations.
  • B3520:This gateway is specialized for Profibus DP Master Protocol integrations.
  • B3521:This gateway is specialized for DeviceNet Master Protocol integrations.

The multiport gateway has support for 1,000 points which can be upgradable to 10,000 allowing it to easily handle multiple protocol drivers and multiple translations simultaneously with no slowdown in performance. The product includes the ports mentioned above depending on the protocol your require. The multiple ports and support for simultaneous protocol execution allow the Multiport Gateway to be used in the most complex integration scenarios. The availability of the second Ethernet port enables the integrator to connect a PC to download configuration changes without disturbing the system connections and without the additional cost of an external hub for the protocol gateway.

Chipkin has been working hand-in-hand with Sierra Monitor from the beginning. We have developed many of their drivers and continue to do so today. We know the product to source code level. If anyone has the capabilities to ensure you succeed in your integration, we are it. Don’t hesitate to CONTACT US for a free consultation.

Multiport Protocol Gateway units can be configured in the field, with all the necessary instructions and software included with the product. If the user prefers the unit to be pre-configured prior to delivery, Chipkin offers and highly recommends custom configuration services.

Example of a BACnet Block Diagram

The Multiport Gateway is approved across a variety of standards, including UL-916, CE, and RoHS. Protocol certifications include the BTL Mark, LonMark, and DNP3 Conformance. These approvals and certifications assure our customers that we carry only the highest quality of standards-compliant products.

With multi-protocol flexibility, ease-of-use, wide deployment, and world-class technical support, the Multiport Protocol Gateway is truly the Swiss Army knife of systems integration. Please CONTACT US for more information or to place an order.

Specifications

Field Connections
  • Ethernet Ports – 2: 100 BaseT RJ45 connector (auto MDIX and sensing) with ESD protection
  • Serial Ports – 5: 2 x RJ45 RS-232 galvanically isolated with ESD protection. 2 x RS-485 galvanically isolated with ESD protection. 1 x RJ45 RS-232 system port.
  • LonWorks – 1: FTT-10 twisted pair. 1000 Network variable capability. LonWorks service pin
  • Auxiliary ports – 2: 2 x USB ports. Expansion: Fieldbus connectors available for selected protocol
  • Depends on Hardware – 1: Profibus DP Slave, Profibus DP Master, DeviceNet Slave, DeviceNet Master, COntrolNet Slave. See Datasheets!
Environment
  • Operating Temperature: 0-60 °C (32-140 °F)
  • Relative Humidity: 10-90% non-condensing
Power Requirements

24V AC (+/-10%) or 12-30V DC @ 12W

Physical Dimensions
  • Dimensions (WxDxH): 6.3x5.4x2.0 in.(16.0x13.7x5.0cm)
  • Weight: 2.5 lbs (1.5 Kg)
  • Input voltage: 24 V DC nominal: 10-30V DC
Other

Configuration/Diagnostic utilities

  • Capacity: Base system has 1000 point capability (upgradeable to 10,000 points)
  • Mounting Options: Desktop, Wall, Panel Optional: DIN rail
LED Indicators

Power, Run, System Error, Configuration Error, and Node Offline

Ethernet connection– Link OK, Tx/Rx communication activity

RS-232/RS-485 – Tx/Rx communication activity

LonWorks - Activity

Communication, Option, Drivers

Memory upgrade for additional data points

Custom Configuration Service

Drivers available for a wide range of Ethernet and social protocols

Approvals
  • CE Marked
  • CSA Certified: UL916 Standard and CSA @ 22.2
  • DNP 3.0 Tested
  • RoHS Compliant
  • GOST-R Certified
  • FCC: Part 15
  • LonMark Certified
  • Modbus Tested
  • BTL Certified
