Discontinued! Modbus RTU to BACnet/IP Soft Gateway

Replaced by MODBUS TO BACNET QUICKSERVER GATEWAY. Modbus RTU to BACnet/IP Windows Gateway acts as a software-based protocol converter. It converts Modbus RTU data and allows it to work on a BACnet/IP Network.
The BACnet IP Driver allows the Gateway to transfer data to and from devices over Ethernet UDP/IP using the BACnet IP protocol.
The Modbus RTU driver allows the Gateway to transfer data to and from devices via a serial RS485 connection using the Modbus protocol.
SKU:
CAS-3000-09
Microsoft Windows - Microsoft Windows Logo

Replaced by MODBUS TO BACNET QUICKSERVER GATEWAY Chipkin's Modbus RTU to BACnet/IP Software Gateway is a Windows-based protocol converter. The gateway operates by reading the data from Modbus RTU devices. The values read from these sensors then can be read from a BACnet/IP network.

The gateway requires minimal configuration and can be considered a "plug and play" component of any network system. It's ready to operate out of the box and can be installed without an engineer's approval.

CAS2500 - Windows

This device is a Software version of our Data Client/Logger and Gateway. It is compatible with an hardware that can load Windows 7 or 10. It allows you to turn any PC that meets the minimum requirements into a Data Client/Logger and Gateway.

BACnet IP Driver

The CAS BACnet IP driver allows the CAS Gateway to transfer data to and from devices over Ethernet UDP/IP using the BACnet IP protocol.  The CAS Gateway can either be a Client, reading and storing values from a BACnet device, or a Server, making data available as BACnet objects.

The CAS BACnet IP Driver supports the following BACnet Services:

- Who-Is- Who-Has
- Read Property- Read Property Multiple
- Write Property- Write Property Multiple
- Subscribe COV     - Time Synchronization

Note: Chipkin is always updating the BACnet IP Driver. For a recent list of supported services, please visit www.chipkin.com or contact us. If there are services that you require that are not listed, please contact us to discuss how we can add them to the driver.

Modbus RTU Driver

The CAS Modbus RTU driver allows the CAS Gateway to transfer data to and from devices via a serial RS485 connection using the Modbus protocol.  The CAS Gateway can either be a Client, reading and controlling values from a slave, or a Server, serving data to a Modbus Master.

The CAS Modbus RTU Driver supports the following Modbus Functions:

- 01 (0x01) Read Coils- 05 (0x05) Write Single Coil
- 02 (0x02) Read Discrete Inputs- 06 (0x06) Write Single Register
- 03 (0x03) Read Holding Registers- 15 (0x0F) Write Multiple Coils
- 04 (0x04) Read Input Registers- 16 (0x10) Write Multiple Registers
I'd like to inquire about the Discontinued! Modbus RTU to BACnet/IP Soft Gateway CAS-3000-09. Please provide me with a quote for this product.

Specifications

CAS2500 - Windows

Minimum Requirements:

  • Operating systems: Windows 7, Windows 10
  • >= 10 mb disk space
  • >= 512 mb ram
  • Ethernet network adapter

If RS232 or RS485 serial connection is needed, an adapter will be required. Chipkin Automation systems suggest ACON U-01.

Block Diagrams

cas-2500 general Windows data client block diagram

Additional Information

CAS 2500/2700 RS485 Connector




Image result for rs485 2 wire to 4 wire
