GE Lighting Controls Support

Lighting Products and Services

Chipkin is the Official authorized service provider for GE lighting controls and an active distributor of their LightSweep System. We are also experts in legacy and current GE lighting control systems and provide a wide range of products and services.

A small summary of what we provide is:

GE Lighting LightSweep

GE's modular indoor lighting control solution is scalable and highly flexible making it easier to meet specifications without having to over-engineer the control design. As GE Lighting's Service provider, Chipkin is your best option to handle all your indoor GE lighting needs. From a single space to multiple facilities, from simple schedules to advanced energy management systems and complete retrofits... our solutions can be easily designed and tailored to address your lighting control needs.

LightSweep is a highly scalable lighting control solution based on relay panels, sensors, and software. Energy reduction schemes include ON/OFF switching and constant dimming based on time schedules, occupancy sensing or daylight harvesting. LightSweep can be integrated with building management systems (BMS) and linked to the "Smart Grid".

Please Contact Us for a free consultation.

Features

Modularity - Easier to meet specification, potentially improving price competitiveness (avoids "over spec"); CAT5 connectivity

Simple Design - Snap-in modules and relays, plug-in connectors enable easy factory or field installation, quick field replacement, and simple upgrades or expansions

Scalability - The system can be scaled from a very simple stand-alone controller, programmed using the push-button feature to a very complex system deployed across multiple buildings or facilities, accessible via the Internet

BACnet - Easier to integrate with 3rd party products (e.g., field devices, BMS, security systems). BACnet controller is a fully programmable device allowing custom programming for very complex applications

Customization - Custom zones, scenes and pre-sets based on user's preferences: conference rooms, multi-purpose rooms, etc.

Chipkin provides Lighting solutions for a wide range of industries. Please Contact Us for a free consultation.

LightSweep Retrofit Kits for the Legacy TLC Panels

We provide the following Kits:

Chipkin provides retrofit kits designed for 24 and 48 relay TLC Legacy Panels. These kits facilitate the conversion of Legacy TLC systems to function with the advanced LightSweep Modular lighting system, enabling users to maintain their legacy system and upgrade it to the latest technology that is currently supported.

Retrofit Kit

As the availability of parts, support, and repairs for the Legacy TLC system continues to decline, retrofitting to the LightSweep will inevitably become mandatory. Choose to prepare for this eventuality by retrofitting your system before it malfunctions which could lead to exorbitant operational costs.

A Retrofit Kit consists of the following components:

  • 2x Relay Module Adapter Plates
  • 1x Group Switch Module Adapter Plate
  • 1x Tub adapter plate
  • 16x screws
  • 16x lock washers
  • 2x long jumpers
  • A Group Switch Module and a Relay Module (for every six relays) are also required and must be purchased separately:
Migration of Douglas Lighting Controls to LightSweep

Following the closure of Douglas Lighting controls, Chipkin are also available to aid in migrating your Douglas Lighting controls project to LightSweep lighting controls system. Our team of experienced lighting engineers can work with you to develop a solution that extends the life of your Legacy Douglas Lighting System by converting the Controls to our modular LightSweep System.

The Douglas relay panels are very similar to that of the Lightsweep panels which makes the conversion to a Lightsweep design economical and straightforward. Please Contact Us for a free consultation.

Total Lighting Control (TLC) Products and Services

If you have an old TLC system, you will definitely need us. Chipkin has official training on how to support, configure, and services these systems. We have access to parts, software tools, and Expertise to solve your problems. Not only that, but we also provide the hardware and services to retrofit upgrade all TCL systems to GE Lightings Modular Lighting System, LightSweep.

With Chipkin's background in integration, we can protect legacy systems through integration or help you upgrade to newer systems. For a list of GE TLC Manuals and Datasheets, Please CLICK HERE.

Our Services

Remote Troubleshooting for Hardware and Software

An experienced engineer or technician versed in GE lighting control systems will support you over the phone. We are also able to use remote desktop software to remotely connect to your computer, in order to configure software and repair connectivity or programming issues. Hourly appointments are available.

Software Graphics, Databases, and O&Ms

Changes over time may create mismatches between what is shown in the software and what exists in the field, and leave existing custom HMI graphics screens dysfunctional. Lighting automation panel software databases can be reconstructed and used to create panel schedules or vice-versa. We are also able to modify existing graphics and create new screens.

If your operations and maintenance manuals are incomplete, out-of-date or you are missing them entirely, we are able to help develop new up-to-date documentation.

On-Site Maintenance and System Survey

The untimely failure of lighting controls can be inconvenient and disruptive, especially for large and commonly used spaces. Our GE authorized service technicians are trained to troubleshoot and perform maintenance to return your system to correct operation.

If your system has not been serviced for many years, it may be in need of a System Survey. We will come to inspect it, exercise the controls, functionally test all components, and document any issues. We will fix what we can and make recommendations for replacements, repairs, or upgrades required to get the system fully operational. We will record scheduling, programming, and sensor setpoint information and ensure panel schedules and documentation are current. We'll inform of any system features that are not set up or that you are not aware of. We are also able to recommend a stock of spare parts and provide training as required.

BMS Integration and Retrofit Upgrades

We are able to interface GE lighting control panels into your building management system, allowing remote monitoring and control of lighting. Utilizing our custom drivers and gateways we can translate TLC communication (proprietary GE protocol, LonWorks) to Modbus, BACnet, Metasys N2 by JCI, Rockwell, GE Fanuc, Omron, SNMP, HTTP and many other popular protocols.

Replacing system components as they fail is cost-effective in the short-term, but as systems get older it often makes sense from a reliability and ROI point-of-view to retrofit or upgrade them. A new system is better supported with available parts/documentation/expertise, is under warranty, and often offers many new features such as occupancy sensors, photosensors, timeclocks, and web/mobile/computer control. We are able to partner with you in upgrading to a system that meets the latest energy codes (ASHRAE, Title 24) and reliably functions for many years to come.

TLC Parts and Software

We assist in finding parts for current and legacy systems. If parts are discontinued or unavailable, we recommend alternatives and upgrades. Limited stocks may be available.

Software: SmartTLC 3.1 (LightX 3.1)
LightX (or SmartTLC) is the software to manage and configure GE Lightings Total Lighting Control Lighting systems.

  • A Windows-based complete control software package that replaces the old DOS based TLC program (RSOFT).
  • The complete control software currently installed on PCs delivered with system. Must speak with one of our representatives.
  • Supports programming, monitoring and control functions for any points in the system.
  • Supports GE Level III hardware for monitor and control of customer lighting
smartlc-31-or-30-ge-tlc-configuration-software

Hardware and other Parts

RR7x Relays (RR7, RR7P, etc., replacements for RR3, RR5), RR9x Relays (RR9, RR9P, etc., replacements for RR4, RR6, RR8), RS2XX Momentary Switch (RS232, RS237, etc.), RP2XX Momentary Switch Plates (RP2112, RP2117, etc.), RA2XX Momentary Switch Blanks, RMP235

RTUB12, RTUB24, RTUB48, RINTER0012RC, RINTER0024RC, RINTER0048RC, RINTERxx12, RINTERxx24, RINTERxx48, RCOV12xxx, RCOV24xxx, RCOV48xxx, RCOV12SL, RCOV24SL, RCOV48SL, RCOV12SHL, RCOV24SHL, RCOV48SHL, RCOV12FHL, RCOV24FHL, RCOV48FHL, TWRLAP12, TWRLAP24, TWRLAP48, RMOTHER-1, RMOTHER-2, RLM48, RGSWT-12, RDLPWR1, RPWR115, RPWR277, RLINK, RREPEAT, RCLOCK, RCABLE-C, RCABLE-M, RPHONE-1, RPHONE-2, (RS1PS7, RS2PS7, RS4PS7, RS8PS7, etc.)

RSOFT-CM1, RSOFT-CMG, RSOFT-CMB, RSOFT-CMGS, RSOFT-CMT, LIGHTX 3.0, SmarTLC 3.1

RPCON, RPCON3-OUT, RMS8 (replacement for RMS5BL, RMS5RL), RMS16, RMS32, RSP12, RSP12, RCS12 (replacement for RSI2)

RPSEN-ATR, RPSEN3-OUT, RPSEN-SKY, RSENSOR-1, RSENSOR-2, RSENSOR-H, RSEN-WLV, RSEN-SM, RSEN-MD, RSEN-LG, RSEN-2H, RTPACK, RTPACK-347, RSEN-W12, RSEN-W3
